    Accurate Plans from Reality

    Professional 2D/3D Floor Plans

    Production-ready floor plans that match the building exactly — no tape measures, no return trips, no surprises.

    TL;DR: Scan-based floor plans hold ±6mm registered accuracy versus ±1/2 inch for tape measurement, with one field day per 100,000 sq ft and DWG/PDF delivery in 3–7 business days.

    2D/3D Floor Plans illustration (not a ZEALOT project image)
    What This Service Is

    2D/3D Floor Plans, explained simply

    We scan your building, then our drafters extract dimensionally accurate 2D and 3D floor plans, elevations, and sections directly from the point cloud. You get clean CAD files in your standards — ready to design, lease, or list.

    Accurate 2D floor plans
    Building elevations and sections
    Site plans and topography
    AutoCAD and other formats
    Talk to a scanning specialist
    2D/3D Floor Plans illustration detail (not a ZEALOT project image)
    Survey-grade

    ±5mm accuracy, NavVis VLX3 mobile LiDAR

    Why It Matters

    Real impact on AEC project outcomes

    Eliminate manual measuring

    Reduce documentation time

    Accurate square footage calculations

    Professional presentation quality

    Easy revisions and updates

    Multiple format delivery

    How It Works

    From kickoff to delivery in 4 clear steps

    1

    Scanning

    We capture all required areas of your building.

    2

    Extraction

    Key features are extracted from point cloud data.

    3

    Drafting

    Professional CAD drawings are produced.

    4

    Review

    You review and approve final deliverables.

    Typical turnaround: the point cloud in days

    Registered point clouds for 2d/3d floor plans projects ship 3–5 business days after capture. Modeled deliverables follow on the timeline stated in the summary above, and the quote fixes the dates before we mobilize.

    Who It's For

    Built for teams that can't afford guesswork

    • Architects starting renovation or fit-out projects
    • Real estate teams marketing or leasing space
    • Facility managers maintaining accurate plans
    • Tenant-improvement contractors
    • Property owners updating outdated drawings
    Problems It Solves

    Stop losing time and money to bad data

    • ✗Inaccurate, decades-old paper drawings
    • ✗Square footage disputes with tenants or buyers
    • ✗Missed dimensions that delay design
    • ✗Hours of manual measurement and redraw
    • ✗Inconsistent plans across floors or buildings
    What You Get

    Specific deliverables, in formats your team already uses

    2D floor plans (.dwg / .pdf) with dimensions
    Building elevations and cross-sections
    Reflected ceiling plans (RCPs) on request
    Site plans and exterior topography
    BOMA-compliant area calculations
    2D/3D Floor Plans illustration (not a ZEALOT project image)
    Example Use Case

    8-floor downtown office tower — leasing plans in 10 days

    A commercial real estate firm needed accurate floor plans for an entire 1970s office tower to support a major lease-up — original drawings were unreliable.

    Result

    We scanned all 8 floors in 3 days and delivered BOMA-rated leasing plans within 10 business days, helping the firm close 4 leases that quarter.

    Pricing

    How modeling is priced

    Scan-to-BIM and CAD deliverables are quoted per project by level of development, discipline count, and building complexity, on top of field capture (typically $0.05–$0.20 per sq ft for scanning and a registered point cloud). Send existing drawings or a site address and you get a scoped number within one business day.

    FAQ

    2D/3D Floor Plans FAQ

    Common questions about our 2D 3D floor plans services

    Complete Guide to 2D/3D Floor Plans

    Accurate 2D and 3D floor plans are fundamental documents for real estate, architecture, facility management, and construction industries. Traditional floor plan creation requires extensive manual measurement—a time-consuming process prone to errors. ZEALOT Reality Capture uses 3D laser scanning to create floor plans with millimeter accuracy, transforming how businesses document their spaces.

    Our 2D 3D floor plan services begin with comprehensive building scanning using the NavVis VLX3 mobile LiDAR system. This technology captures every room, corridor, and space in a fraction of the time required for manual measurement. The resulting point cloud data provides an accurate three-dimensional record from which we extract precise floor plans, elevations, and sections.

    The accuracy of scan-based 2D 3D floor plans exceeds traditional hand measurement by a significant margin. While tape measures introduce human error and often miss small variations, laser scanning captures actual building geometry with ±5mm precision. This accuracy is particularly valuable for renovation projects where exact dimensions impact prefabricated components and finish materials.

    ZEALOT Reality Capture delivers 2D 3D floor plans in industry-standard formats including AutoCAD DWG and PDF. We can follow your layer standards and CAD conventions for seamless integration with existing documentation. Floor plans include all visible architectural elements, dimensions, room labels, and square footage calculations as required for your application.

    From commercial office buildings to industrial facilities, our 2D 3D floor plan services adapt to any building type. We serve clients nationwide from our Ohio headquarters, traveling to project sites across the country. Whether you need a single floor plan or comprehensive building documentation, contact us for a free consultation and discover how scan-based floor plans can benefit your project.
